• Provide powering and  connectivity for up to three (3) UBiFiX DUPLEX units
• Enable powering and communication to each unit via a single Ethernet cable using PoE+
• Provide remote connectivity using LAN and/or built-in cellular modem
• Enable remote operation of the site UBiFiX units via Ubiview centralized control and monitoring tool including:

            - Configuration and Monitoring

            - SW Upgrade

            - Events Logging

            - View of recorded Signals RSSI and Spectrum

PRODUCT HIGHLIGHTS

INTERFERENCE PROTECTION

UBIFIX™

Control Unit

UBiFiX™ Control Unit (UCU)

The UBiFiX™ Control Unit (UCU) provides powering and connectivity to up to three UBiFiX™ DUPLEX spectrum protection systems. The 1U rack mounted (indoor) control unit facilitate simple UBiFiX™ installation indoor or outdoor by using a single cable (CAT5E or higher) to provide both power and connectivity using PoE+ (802.3at). UCU connectivity to UBiFiX™ enables local and remote control, monitoring, SW upgrade and signals RSSI and spectrum logging. The unit enable remote connectivity to the site’s UBiFiX™ units using a LAN port or an integrated cellular modem. Remote connectivity enables logging of the interfered spectrum data on a centralized cloud based server and monitoring the results using the UBiView™ tool.
